Door Closers

Material

• Aluminium Alloy body with forged steel arm

Material Option: Aluminium Alloy, Forged Steel Arm

Detail

• Choice of three closer power sizes (2, 3, 4) with unique high-efficiency cam and roller action
• Suitable where the Equality Act is a consideration
• Standard backcheck and delayed action, with matching adjustable arm
• Body 210 x 48 x 45mm — angle of opening 110°, door thickness 38-45mm
• Rack and pinion, power adjustable by spring, sweep and latching speed adjustable, non-handed

Certification

• In compliance with EN 1634
• In compliance with EN 1154

Finish & US Equivalent

Material

• Aluminium Alloy body with forged steel arm and stainless steel radius cover

Material Option: Aluminium Alloy, Forged Steel Arm

Detail

• Available with radius stainless steel cover, unique high-efficiency cam and roller action
• Suitable where the Equality Act is a consideration
• Adjustable power size 2-4 with choice of standard backcheck and delayed action
• Body 227 x 55 x 39mm — angle of opening 180°, door thickness 38-45mm

Certification

• In compliance with EN 1634
• In compliance with EN 1154

Finish & US Equivalent

Material

• Aluminium Alloy body with forged steel arm and stainless steel radius cover

Material Option: Aluminium Alloy, Forged Steel Arm

Detail

• Heavy duty range, available with radius stainless steel cover
• Unique high-efficiency cam and roller action, suitable where the Equality Act is a consideration
• Adjustable power size 2-5 with choice of standard backcheck and delayed action
• Body 236 x 55 x 39mm — angle of opening 180°, door thickness 38-45mm

Certification

• In compliance with EN 1634
• In compliance with EN 1154

Finish & US Equivalent

Material

• Aluminium Alloy body with forged steel arm and aluminium slide channel

Material Option: Aluminium Alloy, Forged Steel Arm, Aluminium Slide Channel

Detail

• Slide-channel arm variant with radius stainless steel cover available
• Unique high-efficiency cam and roller action, suitable where the Equality Act is a consideration
• Adjustable power size 2-5 with choice of standard backcheck and delayed action
• Body 236 x 55 x 39mm — angle of opening 180°, door thickness 38-45mm

Certification

• In compliance with EN 1634
• In compliance with EN 1154

Finish & US Equivalent

Material

• Aluminium Alloy body with forged steel arm and aluminium slide channel track

Material Option: Aluminium Alloy, Forged Steel Arm, Aluminium Slide Channel

Detail

• Particularly suitable for discreet door control or where there is a high risk of vandalism
• Retro-fit option offers easier fitting — does not require the door frame to be routed for the slide arm track
• Size 3, backcheck and hold-open versions available
• Max door weight 60kg, max door width 950mm — body 230 x 60 x 32mm, angle of opening 120°, door thickness 38-45mm

Certification

• In compliance with EN 1634
• In compliance with EN 1154

Finish & US Equivalent

Material

• Aluminium Alloy body with forged steel arm and aluminium slide channel track

Material Option: Aluminium Alloy, Forged Steel Arm, Aluminium Slide Channel

Detail

• Particularly suitable for discreet door control or where there is a high risk of vandalism
• Retro-fit option offers easier fitting — does not require the door frame to be routed for the slide arm track
• Size 2-4, backcheck and hold-open versions available
• Max door width 850 / 950 / 1100mm, power sizes 2-4 (45-80kg) — body 230 x 36 x 65mm, angle of opening 120°

Certification

• In compliance with EN 1634
• In compliance with EN 1154

Finish & US Equivalent

Material

• Aluminium Alloy body with forged steel arm and aluminium slide channel track

Material Option: Aluminium Alloy, Forged Steel Arm, Aluminium Slide Channel

Detail

• Top mount installation, particularly suitable for discreet door control or high-vandalism-risk areas
• Thermo-constant valve for consistent closing speed across temperatures
• Retro-fit option — does not require the door frame to be routed for the slide arm track
• Size 3 backcheck and hold-open versions available
• Door widths 850 / 950 / 1100mm (45-80kg) — body 286 x 42 x 32mm, angle of opening 120°, door thickness 38-48mm

Certification

• In compliance with EN 1634
• In compliance with EN 1154

Finish & US Equivalent

Material

• Aluminium Alloy body with forged steel arm and aluminium slide channel track

Material Option: Aluminium Alloy, Forged Steel Arm, Aluminium Slide Channel

Detail

• Top mount installation, particularly suitable for discreet door control or high-vandalism-risk areas
• Retro-fit option — does not require the door frame to be routed for the slide arm track
• Size 2-4 backcheck and hold-open versions available
• Door widths 850-1250mm, power size 1-5 (40-100kg) — body 230 x 36 x 40mm, angle of opening 120°, door thickness 38-48mm

Certification

• In compliance with EN 1634
• In compliance with EN 1154

Finish & US Equivalent
